主要特点
Automotive product qualification in accordance with AEC-Q100 (Grade 1)
Wide supply voltage range from 1.65V to 5.5V
Input accepts voltages up to 5.5V
±24mA output drive (VCC=3.0V)
High-impedance when VCC=0V
ESD-HBM: 2000V (AEC-Q100-002)
ESD-CDM: All pins 750V(AEC-Q100-011)
LATCH-UP: ±100mA,Ta=125℃(AEC-Q100-004)
Specified from -40℃ to +125℃
Packaging information: SOT23-5
